Description
Engine type |
Single cylinder, Liquid-cooled, 4-stroke, SOHC |
Displacement |
421cc |
Bore x stroke |
84.5 mm x 75.0 mm |
Compression ratio |
10.0 : 1 |
Lubrication system |
Wet sump |
Fuel system |
EFI – 34mm Mikuni |
Ignition system |
TCI |
Starter system |
Electric |
Transmission system |
L/H/N/R/P, Ultramatic® V-belt with front- and rear wheel engine braking |
Drive system |
On-Command® 2WD, 4WD, 4WD with Diff-lock |
Final transmission |
Shaft |
Front suspension system |
Independent double wishbone, 171 mm wheel travel, 5 position preload adjustment |
Rear suspension system |
Independent double wishbone, 189 mm wheel travel, 5 position preload adjustment |
Front brake |
Dual hydraulic disc |
Rear brake |
Sealed oil-bathed multi-disc |
Front tyres |
AT25x8-12 6ply, E marked / steel wheels |
Rear tyres |
AT25x10-12 6ply, E marked / steel wheels |
