Description
|
Engine type |
Single cylinder, Liquid-cooled, 4-stroke, 4-valves |
|
Displacement |
686cc |
|
Bore x stroke |
102.0 mm x 84.0 mm |
|
Compression ratio |
9.2 : 1 |
|
Lubrication system |
Dry sump |
|
Fuel system |
Fuel injection, 44 mm |
|
Ignition system |
TCI |
|
Starter system |
Electric |
|
Transmission system |
5 speed & reverse, wet multiplate clutch |
|
Drive system |
2WD |
|
Final transmission |
Sealed O-ring chain, eccentric adjustment |
|
Front suspension system |
KYB Piggy Back with Hi and Low speed compression & single rebound adjustment, Independent double wishbone, threaded preload adjustable spring, 230 mm stroke |
|
Rear suspension system |
KYB Piggy Back with Hi and Low speed compression & single rebound adjustment, threaded preload adjustable spring, Cast aluminium swingarm, 256 mm stroke |
|
Front brake |
Dual ventilated disc with hydraulic twin piston callipers |
|
Rear brake |
Dual ventilated disc with hydraulic caliper |
|
Front tyres |
AT21x7R10 |
|
Rear tyres |
AT20x10R9 |
