Description
|
Engine type |
Single cylinder, Liquid-cooled, 4-stroke, SOHC, 4-valves |
|
Displacement |
686cc |
|
Bore x stroke |
102.0 mm x 84.0 mm |
|
Compression ratio |
10.1 : 1 |
|
Lubrication system |
Wet sump |
|
Fuel system |
Electronic Fuel Injection |
|
Ignition system |
TCI |
|
Starter system |
Electric |
|
Transmission system |
L/H/N/R/P, Ultramatic® V-belt with front- and rear wheel engine braking |
|
Drive system |
On-Command® 2WD/4WD/diff-lock |
|
Final transmission |
Shaft |
|
Front suspension system |
Independent double wishbone, 193 mm wheel travel, 5 position preload adjustment |
|
Rear suspension system |
Independent double wishbone, 232 mm wheel travel, 5 position preload adjustment |
|
Front brake |
Dual ventilated hydraulic disc |
|
Rear brake |
Ventilated Disc, left hand/right foot operation |
|
Front tyres |
Maxxis MU19 AT26x8-12, E marked, aluminium wheels |
|
Rear tyres |
Maxxis MU19, AT26x10-12, E marked, aluminium wheels |
